General Review
A broad pass across the sheet for annotation quality, missing data, formatting issues, and red flags — before anything goes to deep review.
FORMATDATAFLAGS
Redline runs the tedious first pass on your MEP drawing sets — clashes, code violations, missing annotations — and hands you a defect list you can approve, dispute, or ignore. Every decision is logged. The stamp stays yours.
A broad pass across the sheet for annotation quality, missing data, formatting issues, and red flags — before anything goes to deep review.
Duct-to-conduit overlaps, clearance conflicts, and routing collisions that would otherwise surface as change orders in the field.
Checks drawings against ASHRAE, NEC, IPC, and IBC references. Every violation is flagged with a citation and a severity rating.
Missing tags, incorrect symbols, unclear callouts, and notation inconsistencies — the things that slow installation crews down.
Inter-discipline gaps between MEP and structural or architectural elements — the conflicts that typically come back as field RFIs.
Deep, comprehensive review for high-stakes sheets. Structured sections with full reasoning and a proposed solution for every defect.
| Rev | Stage | Description | Output |
|---|---|---|---|
| 01 | Upload drawing | Drop in a PDF sheet. Discipline — mechanical, electrical, plumbing — is auto-detected from the filename. | Sheet indexed, ready for review |
| 02 | Pick a mode | Choose from the six analysis modes. Each runs a specialized review informed by code references and engineering practice. | Defect list with severity + citations |
| 03 | Review & dispute | Approve, comment, or dispute each finding. When the AI is wrong, you log why — and your reasoning is preserved with the drawing. | Decision trail, timestamped by author |
| 04 | Stamp & export | Export a PDF report carrying your seal, your drawn signature, and the complete review trail behind every call you made. | PE-stamped, defensible PDF report |
Upload your seal once, draw your signature in the app. Every PDF export carries both — no scanning, no hand-signing.
Approved, ignored, disputed — each defect action is recorded with timestamp and author for defensible documentation.
When a flag is wrong, you log why: not applicable, already addressed, wrong code reference, false positive. The record stays with the drawing.
Never used to train models. Never shared between firms. Strict per-user access controls on every file.
Coordination conflicts, code violations, missing details — with a citation for every finding. Early access is open for MEP firms; we onboard one firm at a time, starting with a 15-minute intake call.
